Selecting the right air conditioner goes beyond assessing cooling capacity; it also involves ensuring the unit’s dimensions are compatible with your space for efficient and hassle-free installation. Accurate measurements play a key role in avoiding potential challenges during setup.
While this guide provides a detailed dimensions chart for both indoor and outdoor units, it’s important to note that air conditioner installation is not a DIY project. For safety, compliance, and optimal performance, always rely on licensed professionals to handle the installation process.
Please note these are the net weights of the units, not the shipping package weights.
We have listed some popular split system brands below. For unlisted models, please refer to the brand brochure available on the brand's official website:
Mitsubishi Heavy Industries- Avanti / Bronte Series:
| Model Number | Capacity |
Dimensions (HXWXD) |
Weight |
| SRK20ZSA-W / DXK06ZSA-W | 2.0kw |
In. 290 x 870 x 230 (mm) Out. 540 x 780 x 290 (mm) |
In. 9.5kg Out. 33kg |
| SRK2ZSA-W / DXK09ZSA-W | 2.5kw |
In. 290 x 870 x 230 (mm) Out. 540 x 780 x 290 (mm) |
In. 10kg Out. 36kg |
| SRK35ZSA-W / DXK12ZSA-W | 3.5kw |
In. 290 x 870 x 230 (mm) Out. 540 x 780 x 290 (mm) |
In. 10kg Out. 36kg |
| SRK50ZSA-W / DXK18ZSA-W | 5.0kw |
In. 290 x 870 x 230 (mm) Out. 640 x 800 x 290 (mm) |
In. 10kg Out. 43.5kg |
| SRK63ZRA-W / DXK21ZRA-W | 6.3kw |
In. 339 x 1197 x 262 (mm) Out. 640 x 800 x 290 (mm) |
In. 15.5kg Out. 45kg |
| SRK71ZRA-W / DXK24ZRA-W | 7.1kw |
In. 339 x 1197 x 262 (mm) Out. 750 x 880 x 340 (mm) |
In. 15.5kg Out. 58kg |
| SRK80ZRA-W / DXK28ZRA-W | 8.0kw |
In. 339 x 1197 x 262 (mm) Out. 750 x 880 x 340 (mm) |
In. 15.5kg Out. 58kg |
| SRK95ZRA-W / DXK33ZRA-W | 9.5kw |
In. 339 x 1197 x 262 (mm) Out. 845 x 970 x 370 (mm) |
In. 16.5kg Out. 70kg |
| SRK100ZR-W | 10.0kw |
In. 339 x 1197 x 262 (mm) Out. 845 x 970 x 370 (mm) |
In. 16.5kg Out. 77kg |
Mitsubishi Heavy Industries- Avanti Plus Series:
| Model Number | Capacity |
Dimensions (HXWXD) |
Weight |
| SRK20ZSXA-W | 2.0kw |
In. 305 x 920 x 220 (mm) Out. 640 x 800 x 290 (mm) |
In. 13kg Out. 43kg |
| SRK25ZSXA-W | 2.5kw |
In. 305 x 920 x 220 (mm) Out. 640 x 800 x 290 (mm) |
In. 13kg Out. 43kg |
| SRK35ZSXA-W | 3.5kw |
In. 305 x 920 x 220 (mm) Out. 640 x 800 x 290 (mm) |
In. 13kg Out. 43kg |
| SRK50ZSXA-W | 5.0kw |
In. 305 x 920 x 220 (mm) Out. 640 x 800 x 290 (mm) |
In. 13kg Out. 45kg |
| SRK60ZSXA-W | 6.0kw |
In. 305 x 920 x 220 (mm) Out. 640 x 800 x 290 (mm) |
In. 13kg Out. 45kg |
Mitsubishi Heavy Industries- Ciara Series:
| Model Number | Capacity |
Dimensions (HXWXD) |
Weight |
| DXK05ZTLA-WF | 1.5kw |
In. 294 x 798 x 210 (mm) Out. 540 x 645 x 275 (mm) |
In. 8.5kg Out. 22kg |
| DXK07ZTLA-WF | 2.0kw |
In. 294 x 798 x 210 (mm) Out. 540 x 645 x 275 (mm) |
In. 8.5kg Out. 22kg |
| DXK09ZTLA-WF | 2.5kw |
In. 294 x 798 x 210 (mm) Out. 540 x 645 x 275 (mm) |
In. 9.0kg Out. 24kg |
| DXK12ZTLA-WF | 3.3kw |
In. 294 x 798 x 210 (mm) Out. 540 x 645 x 275 (mm) |
In. 9.0kg Out. 24kg |
| DXK18ZTLA-WF | 5.0kw |
In. 294 x 798 x 210 (mm) Out. 595 x 780 x 290 (mm) |
In. 9.5kg Out. 33kg |
| DXK21ZTLA-WF | 6.3kw |
In. 294 x 998 x 230 (mm) Out. 640 x 800 x 290 (mm) |
In. 12kg Out. 42.5kg |
| DXK24ZTLA-WF | 7.1kw |
In. 294 x 998 x 230 (mm) Out. 640 x 800 x 290 (mm) |
In. 12kg Out. 40kg |
Mitsubishi Electric- MSZ-LN Series (Wall Mounted):
| Model Number | Capacity |
Dimensions (HXWXD) |
Weight |
| MSZ-LN25VG2(V/B/R)-A3 | 2.5kw |
In. 307 x 890 x 233 (mm) Out. 550 x 800 x 285 (mm) |
In. 15.5kg Out. 33kg |
| MSZ-LN35VG2(V/B/R)-A3 | 3.5kw |
In. 307 x 890 x 233 (mm) Out. 550 x 800 x 285 (mm) |
In. 15.5kg Out. 34kg |
| MSZ-LN50VG3(V/B/R)-A1 | 5.0kw |
In. 307 x 890 x 233 (mm) Out. 714 x 800 x 285 (mm) |
In. 16kg Out. 40kg |
| MSZ-LN60VG3(V/B/R)-A1 | 6.1kw |
In. 307 x 890 x 233 (mm) Out. 880 x 840 x 330 (mm) |
In. 16kg Out. 53kg |
Mitsubishi Electric- MSZ-EF Series (Wall Mounted):
| Model Number | Capacity |
Dimensions (HXWXD) |
Weight |
| MSZ-EF25VG(W/B/S)-A1 | 2.5kw |
In. 299 x 885 x 195 (mm) Out. 550 x 800 x 285 (mm) |
In. 11.5kg Out. 31kg |
| MSZ-EF35VG(W/B/S)-A1 | 3.5kw |
In. 299 x 885 x 195 (mm) Out. 550 x 800 x 285 (mm) |
In. 11.5kg Out. 34kg |
| MSZ-EF42VG(W/B/S)-A1 | 4.2kw |
In. 299 x 885 x 195 (mm) Out. 550 x 800 x 285 (mm) |
In. 11.5kg Out. 35kg |
| MSZ-EF50VG(W/B/S)-A1 | 5.0kw |
In. 299 x 885 x 195 (mm) Out. 714 x 800 x 285 (mm) |
In. 11.5kg Out. 40 kg |
Mitsubishi Electric- MSZ-AP Series (Wall Mounted):
| Model Number | Capacity |
Dimensions (HXWXD) |
Weight |
| MSZ-AP20VGD-A1 | 2.0kw |
In. 250 x 760 x 178 (mm) Out. 550 x 800 x 285 (mm) |
In. 8.2kg Out. 31kg |
| MSZ-AP25VGD2-A1 | 2.5kw |
In. 299 x 798 x 219 (mm) Out. 550 x 800 x 285 (mm) |
In. 10.5kg Out. 34kg |
| MSZ-AP35VGD2-A1 | 3.5kw |
In. 299 x 798 x 219 (mm) Out. 550 x 800 x 285 (mm) |
In. 10.5kg Out. 34kg |
| MSZ-AP42VGD2-A1 | 4.2kw |
In. 299 x 798 x 219 (mm) Out. 550 x 800 x 285 (mm) |
In. 10.5kg Out. 35kg |
| MSZ-AP50VGD2-A1 | 5.0kw |
In. 299 x 798 x 219 (mm) |
In. 10.5kg |
| MSZ-AP60VGD2-A1 | 6.0kw |
In. 325 x 1100 x 257 (mm) Out. 714 x 800 x 285 (mm) |
In. 16kg Out. 40kg |
| MSZ-AP71VGD2-A1 | 7.1kw |
In. 325 x 1100 x 257 (mm) |
In. 17kg |
| MSZ-AP80VGD2-A1 | 8.0kw |
In. 325 x 1100 x 257 (mm) Out. 880 x 840 x 330 (mm) |
In. 17kg Out. 53kg |
Fujitsu- Lifestyle Next Series:
| Model Number | Capacity |
Dimensions (HXWXD) |
Weight |
| ASTH09KMTD-NXT | 2.5kw |
In. 270 x 834 x 222 (mm) Out. 542 x 799 x 290 (mm) |
In. 10kg Out. 32kg |
| ASTH12KMTD-NXT | 3.5kw |
In. 270 x 834 x 222 (mm) Out. 542 x 799 x 290 (mm) |
In. 10kg Out. 32kg |
| ASTH18KMTD-NXT | 5.0kw |
In. 280 x 980 x 240 (mm) Out. 716 x 820 x 315 (mm) |
In. 12.5kg Out. 41kg |
| ASTH22KMTD-NXT | 6.0kw |
In. 280 x 980 x 240 (mm) Out. 716 x 820 x 315 (mm) |
In. 12.5kg Out. 41kg |
| ASTH24KMTD-NXT | 7.1kw |
In. 280 x 980 x 240 (mm) |
In. 12.5kg |
| ASTH30KMTD-NXT | 8.5kw |
In. 340 x 1150 x 280 (mm) Out. 788 x 940 x 320 (mm) |
In. 16.5kg Out. 53kg |
| ASTH34KMTD-NXT | 9.5kw |
In. 340 x 1150 x 280 (mm) |
In. 16.5kg |
Fujitsu- Lifestyle Series:
| Model Number | Capacity |
Dimensions (HXWXD) |
Weight |
| ASTH09KMTD-NXT | 2.5kw |
In. 270 x 834 x 222 (mm) Out. 542 x 799 x 290 (mm) |
In. 10kg Out. 32kg |
| ASTH12KMTD-NXT | 3.5kw |
In. 270 x 834 x 222 (mm) Out. 542 x 799 x 290 (mm) |
In. 10kg Out. 32kg |
| ASTH18KMTD-NXT | 5.0kw |
In. 280 x 980 x 240 (mm) Out. 716 x 820 x 315 (mm) |
In. 12.5kg Out. 41kg |
| ASTH22KMTD-NXT | 6.0kw |
In. 280 x 980 x 240 (mm) Out. 716 x 820 x 315 (mm) |
In. 12.5kg Out. 41kg |
| ASTH24KMTD-NXT | 7.1kw |
In. 280 x 980 x 240 (mm) |
In. 12.5kg |
| ASTH30KMTD-NXT | 8.5kw |
In. 340 x 1150 x 280 (mm) Out. 788 x 940 x 320 (mm) |
In. 16.5kg Out. 53kg |
| ASTH34KMTD-NXT | 9.5kw |
In. 340 x 1150 x 280 (mm) |
In. 16.5kg |
Fujitsu- Comfort Series:
| Model Number | Capacity |
Dimensions (HXWXD) |
Weight |
| ASTH09KNCA | 2.5kw |
In. 270 x 784 x 224 (mm) Out. 541 x 663 x 290 (mm) |
In. 8kg Out. 25kg |
| ASTH12KNCA | 3.4kw |
In. 270 x 834 x 215 (mm) Out. 541 x 663 x 290 (mm) |
In. 9.5kg Out. 25kg |
| ASTH14KNCA | 4.2kw |
In. 270 x 834 x 215 (mm) Out. 542 x 799 x 290 (mm) |
In. 10kg Out. 31kg |
| ASTH18KNTA | 5.0kw |
In. 270 x 834 x 232 (mm) Out. 542 x 799 x 290 (mm) |
In. 11kg Out. 33kg |
| ASTH22KNTA | 6.0kw |
In. 270 x 834 x 232 (mm) |
In. 11kg |
| ASTH24KNTA | 7.1kw |
In. 280 x 980 x 240 (mm) Out. 632 x 799 x 290 (mm) |
In. 12.5kg Out. 39kg |
| ASTH30KNTA | 8.5kw |
In. 340 x 1150 x 280 (mm) |
In. 16.5kg |
| ASTH34KNTA | 9.5kw |
In. 340 x 1150 x 280 (mm) |
In. 16.5kg |
Midea - Apollo Series:
| Model Number | Capacity |
Dimensions (HXWXD) |
Weight |
| MFAB26NB/WB | 2.6kw |
In. 802 x 189 x 297 (mm) Out. 765 x 303 x 555 (mm) |
In. 8.5kg Out. 26.9kg |
| MFAB35NB/WB | 3.5kw |
In. 802 x 189 x 297 (mm) Out. 765 x 303 x 555 (mm) |
In. 8.6kg Out. 28.1kg |
| MFAB50NB/WB | 5.0kw |
In. 1080 x 226 x 335 (mm) Out. 890 x 342 x 673 (mm) |
In. 13.5kg Out. 37.9kg |
| MFAB70NB/WB | 7.0kw |
In. 1080 x 226 x 335 (mm) |
In. 13.7kg |
| MFAB90NB/WB | 9.0kw |
In. 1259 x 282 x 362 (mm) Out. 946 x 410 x 810 (mm) |
In. 19.5kg Out. 64.5kg |
Midea - Gaia Series:
| Model Number | Capacity |
Dimensions (HXWXD) |
Weight |
| MFCA26VA-N/MFCA26VA-W | 2.6kw |
In. 1000 x 212 x 335 (mm) Out. 805 x 330 x 554 (mm) |
In. 13.4kg Out. 32.6kg |
| MFCA35VA-N/MFCA35VA-W | 3.5kw |
In. 1000 x 212 x 335 (mm) Out. 805 x 330 x 554 (mm) |
In. 13.4kg Out. 32.6kg |
| MFCA50VA-N/MFCA50VA-W | 5.0kw |
In. 1088 x 239 x 336 (mm) Out. 890 x 342 x 673 (mm) |
In. 16.2kg Out. 44.5kg |
| MFCA70VA-N/MFCA70VA-W | 7.0kw |
In. 1080 x 239 x 336 (mm) |
In. 16.2kg |
GREE - Alto Hi-Wall Series:
| Model Number | Capacity |
Dimensions (HXWXD) |
Weight |
| GWH09ATBXB -K6DNA1C/I | 2.7kw |
In. 783 x 260 x 185 (mm) Out. 732 x 555 x 330 (mm) |
In. 8.0kg Out. 24.5kg |
| GWH12ATCXB -K6DNA1B/I | 3.5kw |
In. 835 x 275 x 200 (mm) Out. 732 x 555 x 330 (mm) |
In. 8.5kg Out. 27.5kg |
| GWH18ATDXD -K6DNA1C/I | 5.2kw |
In. 943 x 333 x 246 (mm) Out. 802 x 555 x 350 (mm) |
In. 13kg Out. 31.5kg |
| GWH24ATEXF -K6DNA1E/I | 7.1kw |
In. 1078 x 333 x 246 (mm) |
In. 15kg |
| GWH28ATEXF -K6DNA1A/I | 8.2kw |
In. 1078 x 333 x 246 (mm) |
In. 15kg |
GREE - Bora Series:
| Model Number | Capacity |
Dimensions (HXWXD) |
Weight |
| GWH09AAC-K6DNA1A | 2.5kw |
In. 289 x 849 x 215 (mm) Out. 540 x 782 x 320 (mm) |
In. 10.5kg Out. 29kg |
| GWH12AAC -K6DNA1F | 3.4kw |
In. 289 x 849 x 215 (mm) Out. 596 x 848 x 320 (mm) |
In. 10.5kg Out. 33kg |
| GWH18AAD -K6DNA1D | 5.2kw |
In. 300 x 970 x 225 (mm) Out. 646 x 912 x 373 (mm) |
In. 13.5kg Out. 42kg |
| GWH24AAE-IK6DNA1F | 7.1kw |
In. 329 x 1122 x 247 (mm) |
In. 16.0kg |
| HYPER | 9.4kw |
In. 326 x 253 x 1350 (mm) |
In. 19.5kg |
Panasonic - RZ Series:
| Model Number | Capacity |
Dimensions (HXWXD) |
Weight |
| CS-RZ25XKRW | 2.5kw |
In. 290 x 779 x 209 (mm) Out. 542 x 780 x 289 (mm) |
In. 8kg Out. 25kg |
| CS-RZ35XKRW | 3.5kw |
In. 290 x 779 x 209 (mm) Out. 542 x 780 x 289 (mm) |
In. 8kg Out. 30kg |
| CS-RZ42XKRW | 4.2kw |
In. 290 x 779 x 209 (mm) Out. 619 x 824 x 299 (mm) |
In. 8kg Out. 31kg |
| CS-RZ50XKRW | 5.0kw |
In. 290 x 779 x 209 (mm) Out. 619 x 824 x 299 (mm) |
In. 8kg |
| CS-RZ60XKRW | 6.0kw |
In. 295 x 1040 x 244 (mm) |
In. 12kg |
| CS-RZ71XKRW | 7.1kw |
In. 295 x 1040 x 244 (mm) Out. 695 x 875 x 320 (mm) |
In. 13kg Out. 45kg |
| CS-RZ80YKR | 8.0kw |
In. 295 x 1040 x 244 (mm) Out. 695 x 875 x 320 (mm) |
In. 13kg Out. 51kg |
Panasonic - Z Series:
| Model Number | Capacity |
Dimensions (HXWXD) |
Weight |
| CS-Z25XKRW | 2.5kw |
In. 290 x 779 x 209 (mm) Out. 542 x 780 x 289 (mm) |
In. 8kg Out. 25kg |
| CS-Z35XKRW | 3.5kw |
In. 290 x 779 x 209 (mm) Out. 542 x 780 x 289 (mm) |
In. 8kg Out. 30kg |
| CS-Z42XKRW | 4.2kw |
In. 290 x 779 x 209 (mm) Out. 619 x 824 x 299 (mm) |
In. 8kg Out. 32kg |
| CS-Z50XKRW | 5.0kw |
In. 290 x 779 x 209 (mm) Out. 619 x 824 x 299 (mm) |
In. 8kg |
| CS-Z60XKRW | 6.0kw |
In. 295 x 1040 x 244 (mm) |
In. 12kg |
| CS-Z71XKRW | 7.1kw |
In. 295 x 1040 x 244 (mm) Out. 695 x 875 x 320 (mm) |
In. 13kg Out. 45kg |
| CS-Z80XKR | 8.0kw |
In. 295 x 1040 x 244 (mm) Out. 795 x 875 x 320 (mm) |
In. 13kg Out. 60kg |
Kelvinator - Reverse Cycle:
| Model Number | Capacity |
Dimensions (HXWXD) |
Weight |
| KSV25HR | 2.5kw |
In. 802 x 297 x 189 (mm) Out. 885 x 554 x 365 (mm) |
In. 11.2kg Out.35.3kg |
| 2.5kw |
In. 802 x 297 x 189 (mm) Out. 885 x 554 x 365 (mm) |
In. 11.2kg Out. 35.3kg |
|
| KSD35HWH | 3.5kw |
In. 802 x 297 x 189 (mm) Out. 885 x 554 x 365 (mm) |
In. 11.3kg Out. 35.9kg |
| KSD50HWJ | 5.0kw |
In. 1080 x 335 x 226 (mm) Out. 890 x 673 x 342 (mm) |
In. 17.5kg |
| KSD71HWJ | 7.1kw |
In. 1080 x 335 x 226 (mm) |
In. 17.8kg |
Reference Date: 15/01/2025
